A strange finding in the common bile duct
Un hallazgo extraño en el conducto biliar común
Iolanda Ribeiro
Autor para correspondencia

Corresponding author at.
, Rolando Pinho, Luísa Proença, João Carvalho
Centro Hospitalar Vila Nova Gaia, Department of Gastroenterology and Hepatology, Portugal
Información del artículo
Texto completo
Descargar PDF
Figuras (3)
Mostrar másMostrar menos
Texto completo

This is a 75-year-old woman with a past surgical history of laparoscopic cholecystectomy in 2011. In 2013 she presented with an episode of acute cholangitis. An endoscopic retrograde cholangiography (ERCP) with sphincterotomy was performed. Biliary stones were removed and a plastic-metal stent was placed. The stent was removed 3 months later.

The patient presented to our department with recurrent biliary pain in the past few months. Complete blood counts and liver function tests were normal. An abdominal ultrasound showed a mild dilation of the common bile duct (CBD) measuring up to 11mm and a 20mm hiperechogenic linear image within the CBD. An ERCP was performed and confirmed a dilated CBD with a 20mm long linear filling defect (Fig. 1). Biliary sphincterotomy was extended and a balloon sweep revealed biliary sludge and exteriorization of an odd-looking and elongated foreign body (Fig. 2), which proved to be a surgical clip (Hem-o-Lok®clip – Teleflex-USA) (Fig. 3).

Figure 1.

Dilated common bile duct with a 20mm long linear filling defect.

Figure 2.

A odd-looking and elongated foreign body removed from the common bile duct.

Figure 3.

Surgical clip (Hem-o-Lok®clip – Teleflex-USA).


Surgical clip migration following cholecystectomy is a rare but well-documented complication. The timeframe between the initial cholecystectomy and development of complications can be variable with case reports describing migration after as much as 14 years.1 The exact mechanism of clip migration and stone formation remains unclear. Some authors suggest that clips can cause erosion and necrosis of the wall of the CBD leading to migration of the clip. Predisposing factors for clip migration include a short cystic duct stump, inappropriate placement of clips and local infection or suppurative complications around the CBD.2 In most reported cases, the migrated surgical clip acts as a nidus for choledocholithiasis and subsequent biliary obstruction. However, surgical clips alone can also cause symptoms, with few cases previously reported.3 The diagnosis may be suspected based on noninvasive imaging, such as X-ray, ultrasound, CT scan, and MRCP. Abdominal ultrasound is not the best imaging modality to identify surgical clips because clips can mimic biliary stones. Although CT and MRCP can detect clips and their relation to the lithiasis, ERCP is the preferred test because it can simultaneously remove the calculi and the clip4 with a high rate of success.5 Endoclip migration could be potentially avoided by the use of absorbable endoclips, or alternatively ultrasonic dissection without clipping.6

The authors emphasize the rarity of the case and the importance of the differential diagnosis of post-cholecystectomy recurrent choledocholithiasis or abdominal pain.

Conflicts of interest

The authors declare no conflicts of interest.

L.J. Brandt.
Surgical clip migration and stone formation in a gallbladder remnant after laparoscopic cholecystectomy.
Gastrointest Endosc, 70 (2009), pp. 81
K. Kitamura, T. Yamaguchi, H. Nakatani, D. Ichikawa, M. Shimotsuma, T. Yamane, et al.
Why do cystic duct clips migrate into the common bile duct?.
Lancet, 346 (1995), pp. 965-966
K. Das, K. Basu, S. Ray, S. Chatterjee.
Suture material in the common bile duct causing recurrent post-cholecystectomy pain.
Endoscopy, 42 (2010), pp. E258
K.G. Sajith, A.M. Dutta, A.J. Joseph, E.G. Simon, A. Chacko.
Tombstone of surgical clip in common bile duct.
Trop Gastroenterol, 33 (2012), pp. 67-69
V.H. Chong, C.F. Chong.
Biliary complications secondary to postcholecystectomy clip migration: a review of 69 cases.
J Gastrointest Surg, 14 (2010), pp. 688-696
T. Hong, X. Xu, X.-D. He.
Choledochoduodenal fistula caused by migration of endoclip after laparoscopic cholecystectomy.
World J Gastroenterol, 20 (2014), pp. 4827-4829
