Función longitudinal del ventrículo derecho estimada por el desplazamiento sistólico del anillo tricúspide (TAPSE) en 557 pacientes sanos
Right ventricular longitudinal function assessed by tricuspid annular plane systolic excursion (TAPSE) in 557 healthy patients
Visitas
23131
Nilson López1,3,
Autor para correspondencia
nlopez@hptu.org.co

Correspondencia: Unidad de Cardiología. Hospital Pablo Tobón Uribe. Calle 78 B No. 72 A 109. Medellín – Colombia.
, Carlos I. Escobar2,3, Francisco López2,3, Luisa Durango2,3, Ricardo Fernández2,3, Gloria Franco2,3
1 Hospital Pablo Tobón Uribe, Medellín
2 Clínica Cardiovascular Santa María, Medellín
3 Clínica Cardiovascular Santa María. Calle 78B No. 75-21, Medellín, Colombia
Este artículo ha recibido

Under a Creative Commons license
Información del artículo
Resumen
Bibliografía
Descargar PDF
Estadísticas
Objetivo

determinar el valor de referencia del desplazamiento sistólico del anillo tricúspide (TAPSE) en una población de pacientes sin comorbilidades.

Métodos

estudio descriptivo de pacientes adultos atendidos en un servicio de ecocardiografía, sin comorbilidades conocidas y con resultados normales de medidas bidimensionales, Doppler pulsado, continuo y tisular.

Resultados

se analizaron 557 pacientes, con edad (± DE) 43,7±15 años, mujeres 63,5%, quienes tuvieron función sistólica ventricular izquierda conservada (fracción de expulsión 59,8±1% y diámetro telediastólico VI 2,6±0,2cm/m2); no hubo evidencia de disfunción diastólica (onda e' del anillo mitral 12±3cm/s) o hipertensión pulmonar (presión sistólica de la arteria pulmonar 23,8±6mm Hg). El TAPSE promedio fue de 22,6±4mm, sin diferencia significativa entre hombres (23,1±4mm) y mujeres (22,4±3mm). Tampoco hubo variaciones importantes en los resultados de acuerdo con el peso normal, el sobrepeso o la obesidad: 22,6±4mm, 22,7±4mm y 22,7±4mm, respectivamente.

Conclusión

en pacientes con un amplio rango de edad sin enfermedad cardiaca izquierda o derecha y sin hipertensión pulmonar, el valor del TAPSE osciló entre 22mm y 23mm, con un valor inferior de normalidad de 18 mm para la población evaluada.

Palabras clave:
valores de referencia
función ventricular derecha
disfunción ventricular derecha
ultrasonografía
ecocardiografía
Objective

to determine the reference value of tricuspid annular systolic displacement (TAPSE) in a population of patients without comorbidities.

Methods

a descriptive study of adult patients attending an echocardiography service, with no known comorbidities and with normal two-dimensional and Doppler measurements (pulsed continuous and tissue Doppler).

Results

we analyzed 557 patients. Mean age was (± SD) 43.7±15 years. 63.5% were women. All had preserved left ventricular systolic function (ejection fraction 59.8±1% and 2.6 VI diastolic diameter ± 0.2cm/m2). There was no evidence of diastolic dysfunction (wave e ‘of the mitral annulus 12 ± 3 cm/s) or pulmonary hypertension (systolic pulmonary artery pressure 23.8 ± 6 mm Hg). The average TAPSE was 22.6±4mm, with no significant difference between men (23.1±4mm) and women (22.4±3 mm). No significant variations were found in the results according to normal weight, overweight or obesity: 22.6±4mm, 22.7mm and 22.7±4±4mm, respectively.

Conclusion

in patients with a wide range of age without left or right heart disease, and without pulmonary hypertension, the value of TAPSE ranged between 22mm and 23mm, with a lower normal limit value of 18mm for the population studied.

Keywords:
reference values
right ventricular function
right ventricular dysfunction
ultrasound
echocardiography
El Texto completo está disponible en PDF
Bibliografía
[1.]
N.F. Voelkel, R.A. Quaife, L.A. Leinwand, et al.
Right ventricular function and failure: report of a National Heart, Lung, and Blood Institute working group on cellular and molecular mechanisms of right heart failure.
Circulation, 114 (2006), pp. 1883-1891
[2.]
S.Y. Ho, P. Nihoyannopoulos.
Anatomy, echocardiography, and normal right ventricular dimensions.
[3.]
R.M. Lang, M. Bierig, R.B. Devereux, et al.
Recommendations for chamber quantification: a report from the American Society of Echocardiography's Guidelines and Standards Committee and the Chamber Quantification Writing Group, developed in conjunction with the European Association of Echocardiography, a branch of the European Society of Cardiology.
J Am Soc Echocardiogr, 18 (2005), pp. 1440-1463
[4.]
H. Naito, J. Arisawa, K. Harada, H. Yamagami, T. Kozuka, S. Tamura.
Assessment of right ventricular regional contraction and comparison with the left ventricle in normal humans: a cine magnetic resonance study with presaturation myocardial tagging.
Br Heart J, 74 (1995), pp. 186-191
[5.]
R.H. Anderson, M. Smerup, D. Sanchez-Quintana, M. Loukas, P.P. Lunkenheimer.
The three-dimensional arrangement of the myocytes in the ventricular walls.
Clin Anat, 22 (2009), pp. 64-76
[6.]
L.G. Rudski, W.W. Lai, J. Afilalo, et al.
Guidelines for the echocardiographic assessment of the right heart in adults: a report from the American Society of Echocardiography endorsed by the European Association of Echocardiography, a registered branch of the European Society of Cardiology, and the Canadian Society of Echocardiography.
J Am Soc Echocardiogr, 23 (2010), pp. 685-713
[7.]
S. Kaul, C. Tei, J.M. Hopkins, P.M. Shah.
Assessment of right ventricular function using two-dimensional echocardiography.
Am Heart J, 107 (1984), pp. 526-531
[8.]
O.M. Ueti, E.E. Camargo, A. Ueti Ade, E.C. de Lima-Filho, E.A. Nogueira.
Assessment of right ventricular function with Doppler echocardiographic indices derived from tricuspid annular motion: comparison with radionuclide angiography.
Heart, 88 (2002), pp. 244-248
[9.]
J. Kjaergaard, C.L. Petersen, A. Kjaer, B.K. Schaadt, J.K. Oh, C. Hassager.
Evaluation of right ventricular volume and function by 2D and 3D echocardiography compared to MRI.
Eur J Echocardiogr, 7 (2006), pp. 430-438
[10.]
M. Alam, J. Wardell, E. Andersson, B.A. Samad, R. Nordlander.
Characteristics of mitral and tricuspid annular velocities determined by pulsed wave Doppler tissue imaging in healthy subjects.
J Am Soc Echocardiogr, 12 (1999), pp. 618-628
[11.]
E. Hammarstrom, B. Wranne, F.J. Pinto, J. Puryear, R.L. Popp.
Tricuspid annular motion.
J Am Soc Echocardiogr, 4 (1991), pp. 131-139
[12.]
D. Miller, M.G. Farah, A. Liner, K. Fox, M. Schluchter, B.D. Hoit.
The relation between quantitative right ventricular ejection fraction and indices of tricuspid annular motion and myocardial performance.
J Am Soc Echocardiogr, 17 (2004), pp. 443-447
[13.]
S.F. Nagueh, C.P. Appleton, T.C. Gillebert, et al.
Recommendations for the evaluation of left ventricular diastolic function by echocardiography.
J Am Soc Echocardiogr, 22 (2009), pp. 107-133
[14.]
N. Galie, M.M. Hoeper, M. Humbert, et al.
Guidelines for the diagnosis and treatment of pulmonary hypertension: the Task Force for the Diagnosis and Treatment of Pulmonary Hypertension of the European Society of Cardiology (ESC) and the European Respiratory Society (ERS), endorsed by the International Society of Heart and Lung Transplantation (ISHLT).
Eur Heart J, 30 (2009), pp. 2493-2537
[5]
[No authors listed]. Obesity: preventing and managing the global epidemic. Report of a WHO consultation. World Health Organization technical report series 2000; 894: i-xii, 1-253. in press.
[16.]
G.B. Bleeker, P. Steendijk, E.R. Holman, et al.
Assessing right ventricular function: the role of echocardiography and complementary technologies.
Heart, 92 (2006), pp. 19-26
[17.]
P. Morcos, G.W. Vick, D.J. Sahn, M. Jerosch-Herold, A. Shurman, F.H. Sheehan.
Correlation of right ventricular ejection fraction and tricuspid annular plane systolic excursion in tetralogy of Fallot by magnetic resonance imaging.
Int J Cardiovasc Imaging, 25 (2009), pp. 263-270
[18.]
P. Innelli, R. Esposito, M. Olibet, S. Nistri, M. Galderisi.
The impact of ageing on right ventricular longitudinal function in healthy subjects: a pulsed tissue Doppler study.
Eur J Echocardiogr, 10 (2009), pp. 491-498
[19.]
A. Germing, M. Gotzmann, R. Rausse, et al.
Normal values for longitudinal function of the right ventricle in healthy women >70 years of age.
Eur J Echocardiogr, 11 (2010), pp. 725-728
[20.]
M.E. Otto, M. Belohlavek, B. Khandheria, G. Gilman, A. Svatikova, V. Somers.
Comparison of right and left ventricular function in obese and nonobese men.
The Am J Cardiol, 93 (2004), pp. 1569-1572
[21.]
C. Her, T. Cerabona, M. Bairamian, K.E. McGoldrick.
Right ventricular systolic function is not depressed in morbid obesity.
Obes Surg, 16 (2006), pp. 1287-1293
[22.]
Yildirimturk O, Tayyareci Y, Aytekin S. The impact of body mass index on right ventricular systolic functions in normal and mildly obese healthy patients: A Velocity Vector Imaging Study. Echocardiography 2011; May 4. doi: 10.1111/j.1540-8175.2011.01422.x. [Epub ahead of print].
[23.]
S. Ghio, F. Recusani, C. Klersy, et al.
Prognostic usefulness of the tricuspid annular plane systolic excursion in patients with congestive heart failure secondary to idiopathic or ischemic dilated cardiomyopathy.
Am J Cardiol, 85 (2000), pp. 837-842
[24.]
J. Kjaergaard, D. Akkan, K.K. Iversen, L. Kober, C. Torp-Pedersen, C. Hassager.
Right ventricular dysfunction as an independent predictor of short- and long-term mortality in patients with heart failure.
Eur J Heart Fail, 9 (2007), pp. 610-616
[25.]
L. Scuteri, R. Rordorf, N.A. Marsan, et al.
Relevance of echocardiographic evaluation of right ventricular function in patients undergoing cardiac resynchronization therapy.
Pacing Clin Electrophysiol, 32 (2009), pp. 1040-1049
[26.]
F. Cappelli, M. Cristina Porciani, I. Ricceri, et al.
Tricuspid annular plane systolic excursion evaluation improves selection of cardiac resynchronization therapy patients.
Clin Cardiol, 33 (2010), pp. 578-582
[27.]
P.R. Forfia, M.R. Fisher, S.C. Mathai, et al.
Tricuspid annular displacement predicts survival in pulmonary hypertension.
Am J Respir Crit Care Med, 174 (2006), pp. 1034-1041
[28.]
R. Rydman, M. Soderberg, F. Larsen, K. Caidahl, M. Alam.
Echocardiographic evaluation of right ventricular function in patients with acute pulmonary embolism: a study using tricuspid annular motion.
Echocardiography, 27 (2010), pp. 286-293
[29.]
G. Bedetti, L. Gargani, R. Sicari, M.L. Gianfaldoni, S. Molinaro, E. Picano.
Comparison of prognostic value of echographic [corrected] risk score with the Thrombolysis in Myocardial Infarction (TIMI) and Global Registry in Acute Coronary Events (GRACE) risk scores in acute coronary syndrome.
Am J Cardiol, 106 (2010), pp. 1709-1716
[30.]
A. Lopez-Candales, K. Dohi, N. Rajagopalan, K. Edelman, B. Gulyasy, R. Bazaz.
Defining normal variables of right ventricular size and function in pulmonary hypertension: an echocardiographic study.
Postgrad Med J, 84 (2008), pp. 40-45
