Bilateral subtrochanteric femoral fracture due to a very rare disease: Pycnodisostosis
Fractura bilateral subtrocantérica de fémur debido a una enfermedad rara: la picnodisostosis
Visits
1374
A. Delgado González
Corresponding author
alberto.delgado.med@gmail.com

Corresponding author.
, J.J. Morales Viaji, M.E. López Díez
Servicio de Cirugía Ortopédica y Traumatología, Hospital Universitario de Burgos, Burgos, Spain
This item has received

Under a Creative Commons license
Article information
Abstract
Full Text
Bibliography
Download PDF
Statistics
Figures (2)
Tables (1)
Table 1. Summary of cases found in the literature.
Abstract

Pycnodysostosis is a rare autosomal recessive disease caused by a mutation in the cathepsin K enzyme gene, a protease that is expressed primarily in osteoclasts and is responsible for bone matrix degradation. The presentation is usually accompanied by short stature, osteoesclerosis, craniofacial dysmorphia and bone fragility. Some papers provide surgical options for fractures of long bones in this type of patients, but none are presented in European Caucasian patients. The case presented is of a Spanish Caucasian European male with bilateral femoral fracture treated by endomedular nailing.

Keyword:
Pycnodisostosis
Subtrochanteric
Osteopetrosis
Resumen

La picnodisostosis es una rara enfermedad autosómica recesiva causada por una mutación en el gen de la enzima catepsina K, una proteasa que se expresa fundamentalmente en los osteoclastos y que es responsable de la degradación de la matriz ósea. La presentación suele ir acompañada de talla baja, osteoesclerosis, dismorfia craniofacial y fragilidad ósea. Algunos artículos aportan las opciones quirúrgicas para fracturas de huesos largos en este tipo de pacientes pero ninguno se presenta en pacientes de raza caucásica europea. El caso que presentamos es el de un varón español de raza caucásica europea con fractura bilateral de fémur tratada mediante enclavado endomedular.

Palabras clave:
Pycnodisostosis
Subtrochanteric
Osteopetrosis
Full Text
Introduction

Pycnodisostosis is a rare autosomal recessive disease caused by a mutation in the cathepsin K enzyme gene,1 a protease that is expressed primarily in osteoclasts and is responsible for bone matrix degradation. The presentation is usually accompanied by short stature osteosclerosis, craniofacial dysmorphia and bone fragility.2 Some papers provide surgical options for fractures of long bones in this type of patients but none are presented in the literature of our environment.3–5 The case presented is of a middle-aged male with bilateral femoral fracture treated by intramedullary nailing.

Clinical case

A 38-year-old Caucasian European suffered a fall down a staircase and presented with a subtrochanteric fracture of the right femur with pain and external rotation. On physical examination he presented short statue, small hands and feet and typical facial characteristics. No organomegalia was present nor changes to the blood, as have been described in other cases. The patient had no history of having suffered from any other fracture in the past. Of note is the fact that his brother had presented with multiple fractures throughout his life due to the same disease, and genetic diagnosis was therefore available in both patients since childhood, with no need for further testing to be performed. After the radiologic study a displaced subtrochanteric fracture of the right femur was discovered and a coincidental finding of an incomplete subtrochanteric fracture of the left femur which had not led to pain or any other symptoms in that limb (Fig. 1).

Figure 1.

X-ray day of the lesion.

(0.06MB).

Due to the baseline disease intramedullary nailing was planned initially, in accordance with the literature, bearing in mind the narrowness of the medullary canal and the possibility of having to implant flexible paediatric intramedullary nails as an alternative. Surgery was performed under spinal anaesthesia and beginning with the right femur, which was treated with a 340 × 9 mm Recon nail (Stryker, Portage, Minnesota, U.S.A.), two 85 mm cephalic nails and a 65 mm distal static nail. The left femur was synthesized during the same operation with another 340 × 9 mm recon nail (Stryker, Portage, Minnesota, U.S.A.) and two 80 and 90 mm cephalic nails; in this case no distal nail was used. It is very important to point out that the reaming of both medullary canals was extremely difficult due to the bone hardness, with one of the drills even breaking. No other immediate complications arose nor was there any need for transfusion.

The day after the intervention the patient was able to walk with the help of two crutches. Six months after the accident the patient has returned to work with no complications. The right femur was completely cured whilst the left remained without complete consolidation in some points. One year after the accident total recovery of both fractures was observed and the patient lived a completely normal life (Fig.2). In our case in question there were no complications in either the immediate postoperative period nor subsequently.

Figure 2.

Control X-ray after one year.

(0.04MB).
Discussion

Pycnodisostosis is a rare disease, affecting 0.13/100,000 inhabitants (prevalence of Down’s syndrome is 95/100,000).6 Age range at diagnosis in the literature varied from 9 months to 54 years.1 Most patients had been previously diagnosed with hepatosplenomegalia and/or changes to the blood such as chronic anaemia. The most common complication in this type of patients is delayed bone consolidation. Cases of pseudo osteoarthritis, avascular necrosis, fat embolism and other surgical conditions have also been described.2,7,9

There are other metabolic diseases which can cause atypical femoral fractures, such as imperfect osteogenesis, hypophatasia, X-bound osteoporosis, osteopetrosis, X-linked hypophosphatemia, osteoporosis pseudolioma syndrome.8 Several authors describe the problems they found when inserting an intramedullary nail due to bone sclerosis. Kundu et al.1 reported good results regarding recovery and functionality with the endomedullary nail after two years of follow-up, but found there were similar difficulties to ours with osteosynthesis. Due to these difficulties in 2015 Hasem et al. described a successful case treated with plate and nails in this type of fractures although they assumed it could not be extrapolated to all patients, so they concluded that intramedulallary nailing is the best way to treat this type of fractures in patients with pycnodisostosis.2 Whilst osteopetrosis is associated with a high risk of complications, such as aplastic anaemia or hydrocephalus, patients with pycnodisostosis do not usually undergo these risks. The case presented had a complete clinical recovery eight months after the accident. Although the pycnodisostosis is a very rare disease we should be cautious about it because an atypical femoral fracture pattern in young people should make us suspect a metabolic bone disease. To conclude, in our opinion, in keeping with the literature consulted intramedullary nailing of long bones is a favourable treatment for this type of patients (Table 1).

Table 1.

Summary of cases found in the literature.

Case  Race  Age  Management  Complication
Hindu  54  Nailing  No
–  36  Nailing and plate with nails (bilateral fracture)  Surgical site infection
Latina  Plate and nails (bilateral)  No
Hindu  35  Plate and nails  Delayed consolidation
Jewish  49  Plate and nails (bilateral)  No
Asiatic  51  Sliding nail plate (bilateral)  Avascular necrosis
Asiatic  41  Nailing (bilateral)  No
References
[1]
Z.S. Kundu, K.M. Marya, A. Devgan, V. Yadav, S. Rohilla.
Subtrochanteric fracture managed by intramedullary nail in a patient with pycnodysostosis.
Joint Bone Spine, 71 (2004), pp. 154-156
[2]
J. Hasem, R. Krochak, M.D. Culbertson, C. Mileto, H. Goodman.
Atypical femur fractures in a patient with pycnodysostosis: a case report.
Osteoporos Int, 26 (2015), pp. 2209-2212
[3]
P.I. Rojas, N.E. Niklitschek, M.F. Sepulveda.
Multiple long bone fracture in a child with pycnodysostosis. A case report.
Arch Argent Pediatr, 114 (2016), pp. 179-183
[4]
C.J. Yates, M.J. Bartlett, P.R. Ebeling.
An atypical subtrochanteric femoral fracture from pycnodysostosis: a lesson from nature.
J Bone Miner Res, 26 (2011), pp. 1377-1379
[5]
V.G. Roth.
Pycnodysostosis presenting with bilateral subtrochanteric fractures: case report.
Clin Orthop Relat Res, 117 (1976), pp. 247-253
[6]
Prevalencia de las enfermedades raras: datos bibliográ-ficos. Informes periódicos de orphanet, Número 2. Ene 2019. Available from: http://www.orpha.net/orphacom/cahiers/docs/ES/Prevalencia_de_las_enfermedades_raras_por_prevalencia_decreciente_o_casos.pdf.
[7]
T. Yuasa, K. Maeda, K. Kaneko, K. Yoshikata.
Total hip arthroplasty after treatment of an atypical subtrochanteric femoral fracture in a patient with pycnodysostosis.
Case Rep Orthop, 2015 (2015),
[8]
H.H. Nguyen, D.M. Van der Laarschot, A.J.M.H. Verkerk, F. Milat, M.C. Zillikens, P.R. Ebeling.
Genetic risk factors for atypical femoral fractures (AFFs): a systematic review.
JBMR1 Plus, 2 (2018), pp. 1-11
[9]
H.K. Song, Y.B. Sohn, Y.J. Choi, Y.S. Chung, J.H. Jang.
A case report of pycnodysostosis with atypical femur fracture diagnosed by next-generation sequencing of candidate genes.

Please cite this article as: Delgado González A, Morales Viaji JJ, López Díez ME. Fractura bilateral subtrocantérica de fémur debido a una enfermedad rara: la picnodisostosis. Rev Esp Cir Ortop Traumatol. 2021;65:468–470.
